Kia Sedona Front Door Speaker Removal and Replacement Kia Sedona Front Door Speaker Removal 1.1) Roll window down. 1.2) Along front edge of door panel, pry center cap from mounting screw. 2.1) Remove exposed screw. 3.1) Remove screw cap from upper screw on front edge of door panel and remove exposed screw. 4.1) Pry top edge of panel at top of door panel from door releasing clip. All clips release with pry pressure. 5.1) Pry down edge of panel releasing clips. 6.1) Remove panel and set to side. 7.1) Pry edge of small screw cover at door handle cavity. 8.1) Swing screw cover to side for access. 9.1) Remove exposed screw. 10.1) Loosen door handle trim panel. 11.1) Remove door handle trim panel and set to side. 12.1) Pry screw cover from bottom of hand hold on arm rest. 13.1) Remove cover. 14.1) Remove exposed screw. 15.1) Along bottom back edge of door panel, remove screw cover. 16.1) Remove exposed screw. 17.1) Along upper back edge of door panel remove screw cover and remove exposed screw. 18.1) Pry front bottom edge of door panel from door releasing clips. 19.1) Pry up along front edge of door panel releasing clips. 20.1) Pry along bottom edge of door panel releasing clips and up back edge of door panel releasing clips. 21.1) Pull bottom edge of door panel away from door verifying all clips have been released. 22.1) Pull bottom edge of door panel way from door, be sure door handle clears opening in door panel. 23.1) Lift back edge of door panel up out of window jam followed by removing door panel from front of window jam. 24.1) Pull top edge of door panel back for access to back of panel. 25.1) Locate connector on door panel, release trigger on connector to disconnect. 26.1) Locate connector on control panel, release trigger on connector to disconnect. 27.1) On middle connector on driver's door, pry small blue collar on connector up to release trigger. See steps 30 and 31. 28.1) Release trigger on connector to release. 29.1) Remove connector. 30.1) When reinstalling connector, push connector into socket. 31.1) Push blue collar down to lock. 31.2) Remove final connector and set door panel to side. 32.1) Check door for any remaining door panel clips. 33.1) Pry clips from door to remove. 34.1) Slide clips into corresponding slots on door panel ready for reinstallation. 34.1) Release trigger on connector at speaker to disconnect. 35.1) Remove screws securing speaker to door and remove.
How to Remove Kia Sedona Front Side Pillar Tweeter How to Remove and Replace Kia Sedona Front Side Pillar Tweeter 1.1) Open door, pull weather stripping along door open down to release. 2.1) Release weather stripping along edge of front side pillar panel. 3.1) Pry bottom edge of SRS Airbag logo panel from side pillar. 4.1) SRS panel swings to side. 5.1) Remove exposed screw. 6.1) Pry top edge of side pillar panel from vehicle releasing clips. All clips release with pry pressure. 7.1) Grasp top edge of side pillar panel. 8.1) Pull side pillar panel from vehicle releasing remaining clips along panel. 9.1) Grasp lower edge of side pillar panel. 10.1) Pull back slightly from dash then up to remove. 11.1) Lay side pillar panel along dash. 12.1) Release trigger on connector to disconnect and remove panel. 13.1) Remove screws securing tweeter to side pillar panel. 14.1) Bottom edge of side pillar panel has two tongues. 15.1) Side pillar tongues mate to slot in dash when reinstalling. 16.1) Push weather stripping back into place a
Kia Sedona Rear Speaker Removal Presently Not Available
